Products Description
The Stretch Film Slitter Rewinder Machine is specially designed for high-speed precision slitting and rewinding of BOPET, BOPP, BOPE, BOPA, CPP, PETG and other films. It is widely used in the production of flexible packaging and industrial protective films.
Products Description
High-Speed Precision Slitting
The Taiwan Pausource web-correction system and central shaftless rewinding mechanism ensure high-precision slitting within ±0.1mm.
Multi-Mode Slitting
Supports three slitting methods: razor, blaster, and shear, with automatic positioning and blade change to accommodate various film materials.
Stable Structure
A high-strength welded frame and CE-compliant safety interlocks ensure stable and reliable operation even at high speeds.
Intelligent Operation
Touchscreen and PLC control provide full speed and tension monitoring.
|
Model |
DFLM-2800 |
|
Slitting material |
BOPET/BOPP/BOPE/BOPA/CPP/PETG |
|
Material thickness |
6-125um |
|
Material width |
500-2600 |
|
Unwinding diameter |
max. 1200mm |
|
Unwinding core |
3"/6"/Steel Core |
|
Edge Control |
Pausource,Taiwan |
|
Rewinding diameter |
max. 1000mm |
|
Slitting mode |
Centre rewinding and shaftless type |
|
Speed |
Max.800m/min(according to material) |
|
Cutting blade |
Razor blade cut, burst cut, Scissors (automatic cutter position) |
|
Slitting width |
300-2500 mm |
|
Winding core |
3"/6" |
why choose us
20 Years of Industry Experience: Our core team has been deeply engaged in the slitting industry for over two decades, and our equipment is in operation in over 30 countries worldwide.
Leading R&D: Our R&D investment accounts for 15% of our revenue, and we have established a joint laboratory with Zhejiang University. Our equipment boasts an accuracy of ±0.1mm and a speed of up to 800m/min.
Strict Quality Control: Equipped with German servos and high-precision rollers, our equipment has been dynamically balanced and tested for 100 hours of endurance, with an MTBF exceeding 8,000 hours.
Full Service: We provide design, commissioning, training, remote maintenance, and spare parts support.
FAQ
Q: What materials can be slit?
A: Compatible with BOPET, BOPP, BOPE, BOPA, CPP, PETG, and other films with thicknesses of 6–125μm.
Q: Is it customizable?
A: We support customized widths, speeds, slitting methods, and configurations to meet diverse production needs.
Q: Delivery and service?
A: Standard delivery time is 45–60 days, with installation, commissioning, and technical training provided. A 12-month warranty is provided.
Q: How is slitting accuracy guaranteed?
A: Servo control and an automatic web correction system ensure ±0.1mm accuracy.
Q: Will high-speed operation affect quality?
A: An intelligent tension system ensures that the web remains flat and tight even at high speeds.
Q: Is maintenance complex?
A: The modular structure allows for quick replacement of cutters and mandrels; system self-diagnosis reduces maintenance costs.
